Laravel SQRL Authentication

• Introduction
• SQRL versions supported
• Requirements
• Installation
• Configure Log System
• Details to get the project working with full functionality
  • SQRL Authentication
  • SQRL Question
  • IP Address Verification
  • SQRL Disabled
  • SQRL Only Allowed
  • SQRL Hardlock
• Example Instalation
• Classes And Data
  • Sqrl_nonce
  • Sqrl_pubkey
• Functions Availables
  • SQRLController
  • Function to Generate Authenticated Nonce
  • Function to Generate Question Nonce
  • Function to Check If User Can Auth By Normal Login
  • Function to Check If User Can Use Recover Password
  • Function to Check If User Can Auth By SQRL
  • Function to Check If The Nonce Is Ready
  • Function to Get User By Original Nonce If Can Be Authenticated
  • SQRLControllerAPI
  • API Function to SQRL
  • API Function to Check If The Nonce Is Ready
• Installation and Demo Video
• Contacts

Introduction

SQRL(Secure, Quick, Reliable Login) is a draft open standard for anonymous and secure user identification and authentication to websites and web applications, designed to eliminate username and password authentication to remote websites. Users need only to provide one password to unlock their signing keys, which are stored locally on their device and never disclosed to any website. The password is verified locally on the device that stores the signing keys.

Laravel is a free, open-source PHP web framework, created by Taylor Otwell and intended for the development of web applications following the model–view–controller (MVC) architectural pattern and based on Symfony. One of the features of Laravel is a modular packaging system with a dedicated dependency manager.

The following project consists of a laravel module designed to integrate SQRL authentication system to any laravel project.

SQRL versions supported

List of SQRL versions supported in this package and the features that were developed.

• SQRL version 1

We recommend reading these documents:

• SQRL Explained
• SQRL Operating
• SQRL Cryptography
• SQRL On The Wire (Strongly Recommended)

SQRL version 1

• [x] SQRL Authentication;
• [x] SQRL Question (Make question by SQRL features);
• [x] IP Address Verification;
• [x] SQRL Disabled (Disable all SQRL on User Account, if SQRL Client says so);
• [x] SQRL Only Allowed (Block any normal login and allow only by SQRL Authentication, if SQRL Client says so);
• [x] SQRL Hardlock (Block any type of recory password or account, if SQRL Client says so);

Requirements

• PHP >= 7.2.0
• Laravel >= 6.0.0

Installation

You can check the installation process here to Installation and Demo Video.

First, install laravel , and make sure that the database connection settings are correct.

Then run this command to create the necessary tables：

Add the following lines to this file .env.

Verify that the csrf token is not being verified in the route configured in SQRL_ROUTE_TO_SQRL_AUTH (file .env), can be disabled in app/Http/Middleware/VerifyCsrfToken.php with the variable $except by adding the information in SQRL_ROUTE_TO_SQRL_AUTH. (If it's not disabled, the SQRL Client will not be able to communicate with the SQRL Server).

The next step is to copy the routes below to routes/api.php and past the route in the SQRL_ROUTE_TO_SQRL_AUTH (file .env) in this case, below the route the value will be SQRL_ROUTE_TO_SQRL_AUTH=/api/sqrl.

Currently Laravel has a limitation for API calls per user, if your Laravel project locks API calls, consider tinkering with the following file:

And edit in $middlewareGroups the value throttle:60,1 of api, if you don t want to laravel lock the API calls comment throttle:60,1.

Important notice when developing the project, SQRL is only ready to work with https, which means you must have the certificates working.

Configure Log System

This configuration is optional, but strongly recommended for debug purposes in case of any problems. If you want to register or log the information between SQRL server and the SQRL client, this is good for debug purposes, follow the steps below.

Put the code below in the file config\logging.php on the array channels, this will separate the log file per day.

Details to get the project working with full functionality

Here we will talk about how to apply all the available features gradually, in case you do not understand, you always have the Example Instalation chapter and there you can install the example and see how it was implemented while being able to see the SQRL working.

It will be divided into following parts:

• SQRL Authentication
• SQRL Question
• IP Address Verification
• SQRL Disabled
• SQRL Only Allowed
• SQRL Hardlock

SQRL Authentication

This is the functionality to authenticate users to the site. First step, create a nonce for the authenticate user and send it to your login view, like the code below:

More details in Function to Generate Authenticated Nonce.

Second step, check if you have the code below in routes/api.php, this will be the route to communicate to the SQRL Server and to check if the nonce is authenticated.

More details in API Function to Check If is Ready the Nonce.

Third step, put the code exemple below anywhere in your login page , this will be the link and the QR Code for the user to use with the SQRL Client.

More details about QR Code Generator.

Fourth step, copy the script to your html page, this will verify if the next page is ready by the nonce value, it will check every 500 milliseconds (Recommend changing the value).

Fifth step, is to put this code:

on the function was pointed in the variable SQRL_URL_LOGIN(file .env), you can see the function name and controller name in the routes/web.php. You can see the exemples below. SQRL_URL_LOGIN(file .env):

routes/web.php:

Done, now it will be ready for use and testing.

SQRL Question

This is a feature for questioning users by the SQRL application. First step, create a nonce to question user and send it to your login view, like the code below:

More details in Function to Generate Question Nonce.

Second step, check if you have the code below in routes/api.php, this will be the route to communicate to the SQRL Server and to check if the nonce is authenticated.

More details in API Function to Check If is Ready the Nonce.

Third step, put the code exemple below anywhere in your page, this will be the link and the QR Code for the user to use with the SQRL Client.

More Details about QR Code Generator.

Fourth step, copy the script to your html page, this will verify if the next page is ready by the nonce value, it will check every 500 milliseconds (Recommend changing the value).

Fifth step, is to register the user choice on your personal controller, because when the user selects the option it will be redirected to that URL, in that url you save the user choice. The next url depends on the choice and depends on the url you submited on the function of the first step.

Done, noe it will be ready for use and testing.

IP Address Verification

This is the functionality that verifies that the IP Address of the first nonce request is the same as the next requests around that nonce, in some cases this check is not done, for exemple the SQRL Client Mobile, as this is another device that does not have the same IP Address it was saved in request to create nonce. No implementation is required but it is good to know that you have this feature already inserted in the project, so when creating nonces always use the functions of the package, you can check the IP Address in Sqrl_nonce->ip_address. More details in Sqrl_nonce.

SQRL Disabled

This feature is for the SQRL Client to disable SQRL authentication or to disable SQRL Client keys. No implementation is required but it is good to know that you have this feature already inserted in the project, to check if a pubkey is disabled you can check Sqrl_pubkey->disabled, '0' means not disable and '1' is disable. More details in Sqrl_pubkey.

SQRL Only Allowed

Optional Functionality

This feature is for the user to block username and password login feature, this feature is enabled by SQRL Client application.

In order to know if the user as SQRL only allowed, you can perform this function:

More details in Function to Check If User Can Auth By Normal Login. For example you can add this code before allowing user authentication, check if it is allowed:

SQRL Hardlock

Optional Functionality

This feature is so that the user can lock the password recovery feature, this feature is enabled by SQRL Client application.

In order to know if user as SQRL hardlock, you can perform this function:

More details in Function to Check If User Can Use Recover Password. For example you can add this code before allowing the user to recover his password, check if it is allowed:

Example Instalation

First you need to have followed the Install topic before continuing with this topic.

Make sure to follow these steps so that you can install this example. To start run the following command.

The next step is to copy the routes below to routes/api.php.

Finally to finish the installation, you just have to copy the following routes to routes/web.php.

Classes And Data

Here is all the information saved in the database and the classes used.

The list of classes:

• Sqrl_nonce
• Sqrl_pubkey

Sqrl_nonce (DestruidorPT\LaravelSQRLAuth\App\Sqrl_nonce)

The Class Sqrl_nonce contains all the information needed to create a point to start a communicacion between SQRL Server and SQRL Client. Below you can find all the data:

Sqrl_pubkey (DestruidorPT\LaravelSQRLAuth\App\Sqrl_pubkey)

The Class Sqrl_pubkey contains all the information needed to know what SQRL Client is related to the user, in other words it's where all the information about the SQRL Client keys and the user related exists. Once again you can find the data below:

Functions Availables

List of all available features for the implementation of all available SQRL features.

• SQRLController
  • Function to Generate Authenticated Nonce
  • Function to Generate Question Nonce
  • Function to Check If User Can Auth By Normal Login
  • Function to Check If User Can Use Recover Password
  • Function to Check If User Can Auth By SQRL
  • Function to Check If is Ready the Nonce
  • Function to Get User By Original Nonce If Can Be Authenticated
• SQRLControllerAPI
  • API Function to SQRL
  • API Function to Check If is Ready the Nonce

SQRLController (DestruidorPT\LaravelSQRLAuth\App\Http\Controllers\SQRL\SQRLController)

Only use this controller on your own server.

Function to Generate Authenticated Nonce

To generate the Authenticated Nonce, you need to call the function below.

This function will return this array:

Function to Generate Question Nonce

To generate the Question Nonce, you need to call the function below.

This function need these values:

This function will return this array:

Function to Check If User Can Auth By Normal Login

To check if an user can login normally, you need to call the function below.

This function need this value:

This function will return this boolean:

Function to Check If User Can Use Recover Password

To check if the user can recover his password, you need to call the function below.

This function need these values:

This function will return this boolean:

Function to Check If User Can Auth By SQRL

To check if the user can make am SQRL Authentication, you need to call the function below.

This function need this value:

This function will return this boolean:

Function to Check If the Nonce is Ready

This function is necessary for when the user uses SQRL Client Mobile or some SQRL Client that cannot redirect to the user browser, when that happens the user browser needs to check from time to time the nonce, and when the nonce is valid and is of type authentication you need to call the function Get User By Original Nonce If Can Be Authenticated. The function name is below.

This function need this value:

This function will return null if the nonce is null or empty, if nonce is valid it will return this array:

Function to Get User By Original Nonce If Can Be Authenticated

This function is to get the user if the nonce is valid. The function name is below.

This function need this value:

This function will return one of these values:

SQRLControllerAPI (DestruidorPT\LaravelSQRLAuth\App\Http\Controllers\SQRL\SQRLControllerAPI)

This controller is able to integrate other sites with your SQRL Server and for the SQRL client to communicate.

API Function to SQRL

This function is the most important and it's required to use, without this function the SQRL Server will not work, to make the configuration you need to create a route API and put the route in the file .env in the variable SQRL_ROUTE_TO_SQRL_AUTH. Then all communication from SQRL Client will go to this API Function, to see what happens check the log, you can see more information in Configure Log System.

This function will return this array:

API Function to Check If the Nonce is Ready

This function is necessary for when the user uses SQRL Client Mobile or some SQRL Client the cannot redirect the user browser, when that happens the user browser need to check from time to time the nonce, and when the nonce is valid and is a nonce of type authetication you need to call function Get User By Original Nonce If Can Be Authenticated. The function name is below.

This function need this value:

This function will return 404 if the $_GET["nut"] is null or empty, if the nonce is valid it will return this array:

Installation and Demo Video

Click here to go to the video on YouTube

Contacts

• Elton Pastilha:
         Email: [email protected]
         GitHub: DestruidorPT
         WebSite: destruidor.com

• João Ricardo:
         Email: [email protected]
         GitHub: kratezo

• Vladyslav Adamovych:
         Email: [email protected]
         GitHub: nekkiii
