Varnish Purger for Craft CMS

Cache your Craft site in Varnish, and purge exactly the pages that changed when content is saved.

Every page Varnish caches is labelled with what it shows: the entries, assets and categories it outputs, the sections it lists, the Matrix fields it renders. When an editor saves something, the plugin tells Varnish to drop every page with a matching label. Edit an event and only the event page and the listings that show it are purged; the rest of the site stays cached.

The labels are Craft's own element cache tags, the ones behind {% cache %}, so the plugin follows Craft's rules for what a save affects. It uses Varnish's built-in bans, so no Varnish modules are needed.

[!IMPORTANT] This plugin only works together with a VCL tuned for it, and that VCL depends on the site and its hosting. The plugin tags pages and sends BAN requests; Varnish has to cache those tagged pages and turn the BANs into bans. The example VCLs are a starting point, not a drop-in config. Expect to adapt them to things like:

• Your Varnish version: std.ban() needs Varnish 6.6+; on 6.0, use example-varnish-6.0.vcl.
• How requests reach Varnish: behind a proxy, load balancer or CDN, the client IP that acl purge should check may arrive in a header set by that proxy instead of client.ip, and the Craft server may reach Varnish by yet another route.
• Managed hosting: hosts often run their own VCL template, a bypass switch, or a separate purge endpoint that handles BAN/PURGE itself and never reaches your VCL. Find out how to load your own VCL and where it receives requests.
• The site itself: backend address, what must never be cached (login areas, carts, per-visitor content), cookies, and the hostnames it's served under.

Verify the result on the actual setup: php craft varnish/check must answer Ban added, pages must show X-Cache: HIT on a repeat request, and saving an entry must turn its page into a MISS. Test before pointing live traffic at Varnish.

Requirements

• Craft CMS 5.2 or newer, on PHP 8.3 or newer
• Varnish 6.0 or newer in front of your site (tested with 6.0, 6.6 and 7.7)
• Varnish must be reachable from the Craft server, so it can receive purge requests

Installation

Then set up Varnish and tell the plugin where it lives.

1. Set up Varnish

Start from example-varnish-6.0.vcl on Varnish 6.0 (check with varnishd -V, varnishadm banner, or the Via response header). The 6.0 version uses ban() instead of std.ban(), so a ban Varnish can't parse isn't reported back to Craft; otherwise they're identical. Either one:

• only caches pages the plugin has tagged, and passes everything else (the CP, action requests, previews and other token requests, logged-in users, non-GET requests) through to Craft
• never caches private responses (Cache-Control: no-store or private)
• strips cookies from cached pages, and tells browsers not to keep them (Cache-Control: no-cache), so a purge also reaches visitors who saw the page before, and editors who log in see their own version
• drops request headers Craft would use to change the URL, host or site (X-Forwarded-Host, X-Rewrite-Url, X-Craft-Site and the like), so a crafted request can't store a different page under a normal URL. X-Forwarded-Proto is kept and becomes part of the cache key.
• accepts purge requests (BAN) only from the IP addresses in acl purge, and only when they're sent directly rather than relayed through a proxy or load balancer
• adds an X-Cache: HIT/MISS header, handy while testing

Adapt these before going live:

Also set Craft's trustedHosts config setting to the IP addresses of Varnish (and any proxy in front of Craft). By default Craft trusts forwarded headers from any client. The example VCL drops the risky ones, but a request that reaches Craft without passing through Varnish still gets them trusted.

2. Tell Craft where Varnish lives

Go to Settings → Plugins → Varnish and add each Varnish server: its host and port.

• Use the internal address, e.g. 127.0.0.1 port 6081, or the container name in Docker. Not the public site URL: the VCL refuses purge requests that come in through a proxy, CDN or load balancer.
• Add every server that caches the site. Each keeps its own cache, and each gets the purge request.
• The port is usually 6081 for Varnish from Linux packages, and 80 in Docker. Leave it empty for 80.
• Hosts can be environment variables, like $VARNISH_HOST.

Or configure the servers in config/varnish.php. This overrides the CP setting and locks the table. Use Craft's per-environment format to give each environment (CRAFT_ENVIRONMENT) its own servers:

• Set purgeUrls per environment, *not in `''as well**: Craft merges'*'` into the environment and appends lists, so production would ban on both sets of servers.
• Environment keys match on substrings: 'prod' also matches production.
• Leave purgeUrls out for an environment to manage its servers in the CP instead.

Two more options, for hosting setups (config file only):

If no servers are configured, pages are still tagged and cached but nothing is ever purged (logged at info level, so visible with devMode on).

Pages with a lot of tags (long listings showing hundreds of elements) are not tagged, and so not cached, once the X-Cache-Tags header would exceed maxTagsHeaderLength (4000 bytes by default). A warning is logged. A header over Varnish's http_resp_hdr_len (8 KB by default), or over the header buffer of a proxy in between, would fail the whole response. Raise the setting together with those limits if needed.

3. Check that it works

After deploying, check that every configured server accepts bans from this server:

It sends a harmless test ban (a tag no page carries) and exits with an error code if any server fails, so it can run in a deploy script. When Varnish refuses a ban, the answer names the IP it saw: that's the address to add to acl purge.

Then check caching itself:

Request a page twice and look at the headers:

Save one of the entries on that page in the CP, and the next request is a MISS again. Every ban is logged per server with Varnish's answer: failures always (Varnish ban failed (http://… → 403 Forbidden: BAN from 10.0.0.5 …)), successes with devMode on (Varnish banned: … (http://… → 200 Ban added)).

ESI (Edge Side Includes)

Render part of a cached page in its own request, so it can change on every page view while the page around it stays cached:

• Behind Varnish this outputs an <esi:include> tag, which Varnish replaces with the fragment. Anywhere else (no Varnish, novarnish. hosts, console) the template is rendered inline, so templates work either way.
• The fragment is rendered by a plugin action (/actions/varnish/esi/render). Its parameters are signed with Craft's security key, so it can't be used to render arbitrary templates. They're not encrypted, though: the template name and variables are readable in the page source, so don't pass anything secret. It's never cached.
• Pass simple values only (IDs, strings): the fragment is rendered in a separate request, on the same site as the page.
• If a fragment fails to render, Varnish gets an empty fragment and the error is logged (with devMode on, you see the error instead).
• An include inside a {% cache %} block works too: the plugin asks Varnish to process any response that contains an <esi:include> tag.
• Varnish drops the headers of ESI fragments, so a fragment can't set cookies. Don't use it for CSRF tokens: enable Craft's asyncCsrfInputs instead.

example.vcl handles both sides: it sets Surrogate-Capability on requests (so Craft knows it can output ESI tags), and processes responses that send Surrogate-Control: content="ESI/1.0".

Purging everything

Use Utilities → Caches → Varnish cache, or from the command line, which shows each server's answer:

php craft clear-caches/varnish purges everything too. All of these respect the hostnames setting.

How pages are tagged

While the page template renders, Craft records:

• every element the template outputs, including related entries, assets, Matrix entries and anything inside {% cache %} blocks
• every element query, scoped as narrowly as Craft can: by section, entry type, field, volume or group

Tags are shortened to keep the header small:

The element type comes first: e entry, c category, a asset, u user, t tag, g global set, b content block, ad address, p Commerce product, v Commerce variant. Then the scope: s section, t entry type, f field, o owner, g group, v volume, pt product type.

Some details:

• Matrix: saving a nested entry also purges its owner's pages.
• Drafts and revisions never purge anything, so autosaves don't empty the cache.
• Relation fields: Craft tags these queries e:any or c:any, so any entry or category save would purge every page using such a field. The plugin narrows Entries fields to the sections they allow, Categories fields to their category group, and Assets fields to the element that owns the field.
• Structures and Neo: structure queries (entry.ancestors, .children) are narrowed to their section or category group, and Neo content to the entry it belongs to, so saving one entry no longer purges every page with a content builder.
• Search results: pages that use .search() are also tagged e:search. CP saves update Craft's search index in a queue job after the save (and after its purge), so the plugin purges search pages again once that job has run. Otherwise a search re-cached in between would miss the new content.
• Expiry dates: pages are cached until the nearest expiry date of an entry they show, or for Craft's cacheDuration (1 day by default).
• Multi-site: each page also carries its site ID (X-Cache-Site). When a save only changes translatable content (translatable fields, a translatable title), only that site's pages are purged. Anything else purges the affected pages on every site: shared values like untranslatable fields or the post date (Craft copies those to the other sites), new entries, and changes to a version's slug, URI or enabled status (other sites link to it, e.g. from a language switcher). One exception: a page that shows another site's content (craft.entries.site('*')) isn't purged by a change limited to that other site.
• What gets tagged: only front-end GET requests that return 200 and aren't private. Error pages, redirects, CP requests, previews, token requests and responses sent with Cache-Control: no-store or private (for example a page that outputs csrfInput() without asyncCsrfInputs) are never tagged, so Varnish doesn't cache them.

Purge requests

When content changes, the plugin collects the tags Craft invalidates and, at the end of the request (or after each queue job, for queue workers), sends one request to each Varnish server:

X-Cache-Site-Ban is only sent when the change was limited to one site, and X-Cache-Hosts-Ban only when hostnames is configured. The VCL stores the hostname each page was cached under (X-Cache-Host, hidden from visitors) to match it.

Varnish then drops every cached page carrying one of those tags, whatever its URL. Requests go to all servers in parallel. An unreachable server is logged and skipped, and doesn't slow down saving by more than a few seconds.

Known limitations

• Future post dates: an entry scheduled to go live doesn't trigger a purge when it does. Listings pick it up once their cached copy expires.
• Forms and CSRF tokens: Craft marks a page that outputs a CSRF token as private, so it isn't cached. Turn on Craft's asyncCsrfInputs to cache pages with forms: csrfInput() then loads its token with JavaScript.
• No retries: a server that misses a purge keeps its old pages until they expire or the cache is cleared.
• Bulk resaves: bans are merged per request or queue job, so a resave adds one ban per job, not per element. A long import that runs as many jobs still adds many; Varnish's ban lurker clears them in the background. Keep an eye on varnishadm ban.list during large imports.

Development

The tests use Codeception with Craft's test module, and need an empty testing database. The suite wipes and reinstalls it on every run.

tests/_craft/config/db.php sets the connection, and can be overridden with DB_SERVER, DB_USER and DB_PASSWORD. tests/_bootstrap.php clears any CRAFT_DB_* environment variables first, because hosts like ddev set those and they would otherwise point the suite at your project's database. It refuses to run unless the database resolves to testing.

In ddev:

CI runs ECS, PHPStan and the tests on every push and pull request (.github/workflows/ci.yml).

AI agents working with this plugin (installing it, writing a VCL, debugging a hosting setup) should also read AGENTS.md: it has the background, edge cases and hosting pitfalls in full.
